GP series

The display technology required in the display market is becoming more and more advanced. In line with this, the GP series measures the goniophotometric characteristics of large displays, Micro-LEDs, and OLEDs up to 2,400mm. It can handle a wide range of lighting fixtures from room lighting to floodlights and is customizable to meet your multi-purpose needs.

 Features
  • Up to 2,400mm of LED lightings can be measured

  • Compatible with Micro-LED, OLED and large display's goniophotometric measurement

  • By automatically controlling a biaxial goniometer to measure spectral distribution at every angle, spectral total radiant flux, total luminous flux, chromaticity, color temperature, etc. can be obtained

  • The newly adopted detector has a wide dynamic range

  • Compliant with IESNA LM-75 and CIE121

  • Optic type B and C can be chosen at the same time(in case of GP-2000)
  • Spectral radiant flux can be calculated even in UV - NIR light area
 Specifications
ModelGP-500GP-1100GP-2000
*Opticstype Ctype Ctype B, type C
Optical path length< 500mm500 ~ 1,500mm1,500 ~ 12,000mm
Measurable sampleLED chipMicro-LED, Mini-LED panelgeneral lighting
incl. fluorescent tube
Detectorarray spectrometer
Wavelength**360 ~ 830nm

*two-axis goniometer

**wavelength for the detector can be adjustable



Types of the coordinate system in light distribution measurement(JIS C 8105-5)

Coordinate
system
Vertical angleHorizontal angleIESNA LM-75
MarkRangeMarkRange
αβ
α
-90° ≦ α ≦ 90°
β
-180° ≦ β ≦ 180°
type B
θφ
θ
0° ≦ θ ≦ 180°
φ
0° ≦ φ ≦ 360°
type C


Measurement images of Type B and C


 Measurement
Measurement items
  • Angular distribution(light distribution)

  • Spectral radiant flux(spectrum)

  • Chromaticity(u,v) 〔CIE 1960UCS〕

  • Spectral radiant intensity(spectrum)

  • Chromaticity(u’,v’) 〔CIE 1976UCS〕

  • Chromaticity(x,y) 〔JIS Z 8724〕

  • Dominant wavelength and Excitation purity 〔JIS Z 8701:1999〕

  • Correlated color temperature and Duv 〔JIS Z 8725〕

  • Color rendering index(Ra, R1 ~ R15) 〔JIS Z 8726〕


 System configuration

System configurations of Type B and C
